HIGHLIGHTS

• High Speed Production

  Welding of 60 to 70 Nuts per Minute is possible with one machine and one operator

• Operator safety

  No need for operator to put nut between electrodes and as such no possibility of accidental injury to the operator

• Right placement

  Nut is placed with right orientation every time. Thus savings from probable damaged parts, damage to electrodes

• No Wastage

  Nuts do not fall down on shop floor, saving the material wastage

• Easy to setup

  Takes only a few hours for installation and is productionized on same day

• Auto/Manual functions

  Facilitates welding of different nuts by switching of nut feeder and can operate only spot welder

• Auto switch off for vibrator

  Saves power by switching off the vibrator when the supply hose is full

SPECIFICATIONS

• Operating Voltage

  415V AC

• Supply Frequency

  50 Hz

• Air Supply

  4.5 to 5 bar

• Bowl capacity

  Around 10,000 Nuts

• Feed rate

  60-70 Nuts per Minute for M6
  50-60 Nuts per Minute for M10
